ABM-A8105D32 Die Making Auto Bender Machine included functions:Broaching,Bending,Bridge,Nicking,Perforation,Lipping and Cutting. Supported steel rule thickness 0.45,0.53,0.71,1.05mm,height 8-32mm. Adewo has been successful for many domestic and foreign die making&printing companies to provide advanced Auto Bender Machines, technical support and excellent after sales service.
Shenzhen Adewo Automation Technology Co.,ltd. is Die Making Auto Bender Machine manufacturers and suppliers in China who can wholesale Die Making Auto Bender Machine. We can provide professional service and better price for you. If you interested in Die Making Auto Bender Machine products, please contact with us. We follow the quality of rest assured that the price of conscience, dedicated service.Sincerely look forward to cooperating with you in the near future
Picture of (ABM-A8105D32)Die Making Auto Bender Machine:
1.Multi-Functions:(ABM-A8105D32)Die Making Auto Bender Machine with Broaching,Bending,Bridge,Nicking,Perforation,Lipping and Cutting.
2.Punching Tools in this Die Making Auto Bender Machine is specially designed for high-requirement die boards such as cigarette cases,pill boxes,electronic dies and etc.
Two sets Lipping&Cutting Tools customize based on the cutting rule bevel degree, to get high precision seamless cut and Lip cut.
3. Multiple sets Broaching&Nicking: This Die Making Auto Bender Machine with 4PCS Broaching saw blades 4PCS.The width&depth of Broaching can be adjusted by the software. Different size Nicking done by 1PC Nicking Saw blade.
4. Double-clips Feeding:This Die Making Auto Bender Machine with two feeding clips which for improves feeding speed and accuracy.
5. Smart Software: This
Die Making Auto Bender Machine with independently developed software supports the formats of CAD files.User-friendly software interface, easy to operate.
6. Auto Rule Cassette with display: 6 different types of steel rule can be installed, humanized design, convenient to change different rule. It is independent, can be placed and moved at will.
7.Samples done by (ABM-A8105D32)Die Making Auto Bender Machine:
|
Supported Rule Thickness(mm) |
0.45,0.53,1.07,1.05mm(1pt,1.5pt,2pt,3pt) |
|
Supported Rule Height(mm) |
8-32mm |
|
Min.Arc Radius of 90 Degree |
0.4mm |
|
Front Min.Bending Size |
1.5mm |
|
Back Min. Cutting Size |
1.0mm |
|
Feeding Precision |
±0.03mm |
|
Bending Flatness |
±0.2mm/100mm |
|
Bridge Width |
5mm(can be customized) |
|
Bridge Height |
12-20mm(Adjustable) |
|
Functions |
Bending, Bridge,Lipping,Cutting, Broaching, |
|
Cutting Methods |
Lipping Cut,Seamless Cut |
|
Optimal Graphic Format |
DXF,DWG |
|
Air supply |
0.4-0.8Mpa |
|
Power Supply |
Single Phase,AC220V,13.6A,50-60Hz |
|
Machine Total Power |
3KW |
|
Machine Weight |
480KGS |
|
Machine size |
2800x930x1600(L×W×H) |
|
H.S. Code |
8462230000 |
1.How long is the warranty of the machine?
One year guarantee for machine is promised.
Even after the warranty period, we still give long-term technical support and consultation
If any problems during the use of the machine, users can contact with Adewo after-sales technicians at any time.
2.How about installation and training?
English software, installation, related training user manual and videos are available for end-users.
We provide remote support to customers all over the world.
Our technical service is always available at services@china-adewo.com
3.What’s price term?
(1)FOB Shenzhen China
(2)CIF
(3)DDP
4. What’s payment term?
30% T/T as down payment, 70% T/T before delivery.
5.What’s about delivery time?
7-10 working days upon your 30% T/T advance payment.
