(ABM-A8105)Basic Model Die Boards Prolsil Stante Auto Bending Machine included functions:Bending,Bridge,Lipping and Cutting. Supported steel rule thickness 0.45,0.53,0.71,1.05mm, height 8-30mm. China Adewo has two factories in China,specializing in developing and manufacturing die cutting equipments including CNC Laser Cutting Machine,Automatic Bender Machine, Creasing Cutting Machine and so on in Packaging Industry.
As the professional manufacture, we would like to provide you Basic Model Die Boards Prolsil Stante Auto Bending Machine. And we will offer you the best after-sale service and timely delivery.After-sale services : after-sales team will deal with all complaint from customers such as packaging ,quality ,shipping ,etc. We will surely exchange goods or make up lost if finally verify mistakes caused by our side, a promise is a promise !
Picture of (ABM-A8105)Basic Model Die Boards Prolsil Stante Auto Bending Machine
1.Multi-Functions：(ABM-A8105)Basic Model Die Boards Prolsil Stante Auto Bending Machine with Fast and Accurate Bending, Multi-Bridging,Pneumatic Lipping, Cutting.
2.This Basic Model Die Boards Prolsil Stante Auto Bending Machine uses Panasonic Servo motor system, high precise ball-screw guide feeding system.
3.Smart software and easy to operate, multi language operations;
4. Save production time and easy for die making by Basic Model Die Boards Prolsil Stante Auto Bending Machine.
5.This Basic Model Die Boards Prolsil Stante Auto Bending Machine apply to various kinds of mold processing, such as corrugated dies,stripping dies,rotary dies etc.
|
Supported rule thickness(mm) |
0.45/0.71/1.05mm |
|
Supported rule height(mm) |
8-30mm |
|
Bridge height |
15-18mm |
|
Bridge width |
Over 5mm any sizes available. |
|
Min. ARC radius of 90 degree |
±0.3MM |
|
Front Min. bending size |
1.5MM |
|
Back Min. cutting size |
1.0MM |
|
Feeding precision |
±0.03mm |
|
Bending flatness |
±0.2mm |
|
Functions |
Bending, Bridging, Offline Pneumatic lipping, Cutting |
|
Cutting methods |
Twist off and Auto flat cutting |
|
Optimal pattern format |
DXF,DWG |
|
Air supply |
0.4-0.8mpa |
|
Power supply |
Single Phase AC220V,13.6A,50-60Hz |
|
Machine total power |
3KW |
|
Weight |
458KGS |
|
Overall dimension |
2.1×0.81×1.22m(L×W×H) |
|
H.S. Code |
8462219000 |
1.What’s price term?
(1)FOB Shenzhen China
(2)CIF
(3)DDP
2. What’s payment term?
30% T/T as down payment, 70% T/T before delivery.
3.What about lead time of Die Boards Prolsil Stante Auto Bending Machine?
7-10 working days.
4.How about installation and training of Die Boards Prolsil Stante Auto Bending Machine?
English software, installation, related training user manual and videos are available for end-users.
We provide remote support to customers all over the world.
Our technical service is always available at services@china-adewo.com
5.Any spare tools are included of Die Boards Prolsil Stante Auto Bending Machine?
Yes,the new order machine with free spare tools.
